Data logger for temperature and humidity KH-70

Digital thermometer

Perfectly adapted to winehouses, this data logger is very easy to set up and read.

Add to my quote request
  • 411200 Data logger for temperature and humidity
    Quantity:
    Add this item to quote

Références concernées

  • 411200Data logger for temperature and humidity

TECHNICAL FEATURES

  • CMOS sensor
  • Measurement range from 0 to 100 % RH / from -20 to +70 °C
  • Accuracy:
- ± 2%RH (from 15°C to 25°C)
Factory calibration uncertainty: ± 0.88 %RH
Drift linked to temperature: ±0.04 x (T-20) %RH (if T<15°C or T>25°C)

From - 20 to 0°C: 2% of reading± 0.6 °C
From 0 to 30 °C: 0,5 °C
From 30 to 70 °C: 1.5% of reading
  • Response time (t0.63): 50 s (Vair = 2 m/s) / 50 s (Vair = 2 m/s)
  • Display units: °C, °F, %RH
  • Resolution : 0.1 °C, 0.1 °F, 0.1%HR,
  • Measurement rate from 1 minute to 24 h
  • Operating temperature from -20 to +70°C
  • Battery type: lithium 3.6 V ½ AA
  • Battery life:5-year (1 measuring every 15 minutes at 25°C)
  • Input connector: Input connector/stereo output Jack 2.5 / Jack  3.5
  • Buttons: 2 control buttons (Select / OK)
  • Protection sign: IP 40 protection rating
  • Dimensions: 100 x 42.5 x 15.9 mm
  • Weight: 53g

ADVANTAGES

  • • 2 parameters: humidity and temperature
    • 2 recording modes, 3 types of start measures, 6 types of recording stop
    • LCD display with one line
    • 2 configurable setpoint alarms
    • Free downloadable configuration and data visualization software (KILOG-LITE)
    • USB included
    • Up to 50 000 recording points
    • IP40 housing
    • Magnetic or wall mounting installation
    • Storage temperature from -40 to +85 °C
